Table of Contents

Introduction to Random Forest

Random Forest Implementation

Best Practices for Interpreting Random Forest

Conclusion

Introduction to Random Forest


Pre-requisites: Decision Trees












What is Random Forest?








Why Random Forest?




How Random Forest Works?
















Benefits of Random Forest

  • Works for both classification and regression
  • Handles categorical features naturally
  • No assumption of distributions
  • Can handle non-linear interactions
  • No need for feature scaling / transformation
  • Handles missing values in the variables

Advantages:

  • Built in cross validation (OOB Scores)
  • Built in Feature Selection (implicit)
  • Feature importance
  • Default hyper parameters are great and Works well "off the shelf"
  • Minimum hyper parameter tuning
  • RF natively detects interactions
  • It's non-parametric (you don't have to make any assumptions of your data)

Disadvantages:

  • RF is a black box (It's literally a function of 1000 decision trees)
  • It doesn't tell you "how" the features are important


Random Forest Implementation



Import Libraries

In [119]:
import warnings
import numpy as np
import pandas as pd
import seaborn as sns
import matplotlib as matplot
import matplotlib.pyplot as plt

from sklearn.metrics import roc_auc_score
from sklearn.preprocessing import StandardScaler
from sklearn.model_selection import cross_val_score
from sklearn.ensemble import RandomForestClassifier


%matplotlib inline
warnings.filterwarnings("ignore")

Import Titanic Dataset

In [107]:
# Import the Titanic Dataset
X = pd.read_csv('titanic_train.csv')
X.shape
X.head()
Out[107]:
(891, 12)
Out[107]:
PassengerId Survived Pclass Name Sex Age SibSp Parch Ticket Fare Cabin Embarked
0 1 0 3 Braund, Mr. Owen Harris male 22.0 1 0 A/5 21171 7.2500 NaN S
1 2 1 1 Cumings, Mrs. John Bradley (Florence Briggs Th... female 38.0 1 0 PC 17599 71.2833 C85 C
2 3 1 3 Heikkinen, Miss. Laina female 26.0 0 0 STON/O2. 3101282 7.9250 NaN S
3 4 1 1 Futrelle, Mrs. Jacques Heath (Lily May Peel) female 35.0 1 0 113803 53.1000 C123 S
4 5 0 3 Allen, Mr. William Henry male 35.0 0 0 373450 8.0500 NaN S
In [108]:
y = X.pop("Survived")
y.shape
y.head()
Out[108]:
(891,)
Out[108]:
0    0
1    1
2    1
3    1
4    0
Name: Survived, dtype: int64

Quick Data Cleaning and Data Imputation

  • Dropped unimportant features (PassengerId, Name, Ticket)
In [109]:
# Drop PassengerId, Name, Ticket
X.drop(['PassengerId','Name','Ticket'], axis=1, inplace=True)
In [110]:
def clean_cabin(x):
    try:
        return x[0]
    except TypeError:
        return "None"
In [111]:
# Clean Cabin
X["Cabin"] = X.Cabin.apply(clean_cabin)
  • Imputed missing values in features (Age)
In [112]:
# Impute missing age with median
X["Age"].fillna(X["Age"].median(), inplace=True)
  • Dummified categorical features (Sex, Cabin, Embarked)
In [113]:
# Define categorical features
categorical_variables = ["Sex", "Cabin", "Embarked"]
In [114]:
# Impute missing categorical variables and dummify them
for variable in categorical_variables:
    X[variable].fillna("Missing", inplace=True)
    dummies = pd.get_dummies(X[variable], prefix=variable)
    X = pd.concat([X, dummies], axis=1)
    X.drop([variable], axis=1, inplace=True)
In [115]:
X.shape
X.head()
Out[115]:
(891, 20)
Out[115]:
Pclass Age SibSp Parch Fare Sex_female Sex_male Cabin_A Cabin_B Cabin_C Cabin_D Cabin_E Cabin_F Cabin_G Cabin_None Cabin_T Embarked_C Embarked_Missing Embarked_Q Embarked_S
0 3 22.0 1 0 7.2500 0 1 0 0 0 0 0 0 0 1 0 0 0 0 1
1 1 38.0 1 0 71.2833 1 0 0 0 1 0 0 0 0 0 0 1 0 0 0
2 3 26.0 0 0 7.9250 1 0 0 0 0 0 0 0 0 1 0 0 0 0 1
3 1 35.0 1 0 53.1000 1 0 0 0 1 0 0 0 0 0 0 0 0 0 1
4 3 35.0 0 0 8.0500 0 1 0 0 0 0 0 0 0 1 0 0 0 0 1

Split into Train & Test Set

In [116]:
from sklearn.model_selection import train_test_split

X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.20, random_state=42)

Fitting on Numeric Features

In [117]:
# Get a list of numerical features
numeric_variables = ['Pclass','Age','SibSp','Parch','Fare']
X_numeric = X_train[numeric_variables]
X_numeric.shape
X_numeric.head()
Out[117]:
(712, 5)
Out[117]:
Pclass Age SibSp Parch Fare
331 1 45.5 0 0 28.5000
733 2 23.0 0 0 13.0000
382 3 32.0 0 0 7.9250
704 3 26.0 1 0 7.8542
813 3 6.0 4 2 31.2750
In [13]:
from sklearn.ensemble import RandomForestClassifier

# Create the baseline
model_1 = RandomForestClassifier(oob_score=True, random_state=42)

Out-of-Bag Score (Built in Cross Validation)

In [14]:
# Fit and Evaluate OOB
model_1 = model_1.fit(X_numeric, y_train)

# Calculate OOB Score
print("The OOB Score is: " + str(model_1.oob_score_))
The OOB Score is: 0.6544943820224719

Cross Validation Score

In [15]:
from sklearn.model_selection import cross_val_score

# CV Score
rf_result = cross_val_score(model_1, X_numeric, y_train, scoring='accuracy')
rf_result.mean()
Out[15]:
0.6601129903438169

AUC Score

In [16]:
from sklearn.metrics import roc_auc_score

# AUC Score
pred_train = np.argmax(model_1.oob_decision_function_,axis=1)
rf_numeric_auc = roc_auc_score(y_train, pred_train)
rf_numeric_auc
Out[16]:
0.613520236654565

Fitting on Categorical and Numerical Features

Copy original training set

In [17]:
# Copy the whole train set
X_cat = X_train.copy()
In [118]:
X_cat.shape
X_cat.head()
Out[118]:
(712, 20)
Out[118]:
Pclass Age SibSp Parch Fare Sex_female Sex_male Cabin_A Cabin_B Cabin_C Cabin_D Cabin_E Cabin_F Cabin_G Cabin_None Cabin_T Embarked_C Embarked_Missing Embarked_Q Embarked_S
331 1 45.5 0 0 28.5000 0 1 0 0 1 0 0 0 0 0 0 0 0 0 1
733 2 23.0 0 0 13.0000 0 1 0 0 0 0 0 0 0 1 0 0 0 0 1
382 3 32.0 0 0 7.9250 0 1 0 0 0 0 0 0 0 1 0 0 0 0 1
704 3 26.0 1 0 7.8542 0 1 0 0 0 0 0 0 0 1 0 0 0 0 1
813 3 6.0 4 2 31.2750 1 0 0 0 0 0 0 0 0 1 0 0 0 0 1
In [19]:
# Create the baseline
model_2 = RandomForestClassifier(oob_score=True, random_state=40)

Out-of-Bag Score (Built in Cross Validation)

In [20]:
# Fit and Evaluate OOB
model_2 = model_2.fit(X_cat, y_train)

# Calculate OOB Score
print("The OOB Score is: " + str(model_2.oob_score_))
The OOB Score is: 0.7963483146067416

Cross Validation Score

In [21]:
rf_result = cross_val_score(model_2, X_cat, y_train, scoring='accuracy')
rf_result.mean()
Out[21]:
0.7837227718091455

AUC Score

In [22]:
# AUC Score
pred_train = np.argmax(model_2.oob_decision_function_,axis=1)
rf_cat_auc = roc_auc_score(y_train, pred_train)
rf_cat_auc
Out[22]:
0.7694130697862042

Feature Scaling?

Does Scaling Affect Performance? Is it neccessary for tree based models?

In [23]:
from sklearn.preprocessing import StandardScaler

# Scaling training data
X_cat_scaled = StandardScaler().fit(X_cat).transform(X_cat)
X_cat_scaled
Out[23]:
array([[-1.61413602,  1.25364106, -0.47072241, ..., -0.05307449,
        -0.30335547,  0.59681695],
       [-0.40055118, -0.47728355, -0.47072241, ..., -0.05307449,
        -0.30335547,  0.59681695],
       [ 0.81303367,  0.21508629, -0.47072241, ..., -0.05307449,
        -0.30335547,  0.59681695],
       ...,
       [ 0.81303367,  0.90745614,  1.23056874, ..., -0.05307449,
        -0.30335547,  0.59681695],
       [-1.61413602, -1.1696534 ,  0.37992316, ..., -0.05307449,
        -0.30335547,  0.59681695],
       [-1.61413602, -0.63114352, -0.47072241, ..., -0.05307449,
        -0.30335547,  0.59681695]])

Fit Standardized Training Set

In [24]:
# Create the baseline
model_3= RandomForestClassifier(oob_score=True, random_state=40)

# Fit and Evaluate OOB
model_3 = model_3.fit(X_cat_scaled, y_train)

# Calculate OOB Score
model_3.oob_score_
Out[24]:
0.7949438202247191

Evaluate Scores

Baseline RF Model Evaluation (ROC AUC)

In [25]:
from sklearn.metrics import roc_curve

# Create ROC Graph
rf_numeric_fpr, rf_numeric_tpr, rf_numeric_thresholds = roc_curve(y_test, model_1.predict_proba(X_test[X_numeric.columns])[:,1])
rf_cat_fpr, rf_cat_tpr, rf_cat_thresholds = roc_curve(y_test, model_2.predict_proba(X_test)[:,1])

# Plot Random Forest Numeric ROC
plt.plot(rf_numeric_fpr, rf_numeric_tpr, label='RF Numeric (area = %0.2f)' % rf_numeric_auc)

# Plot Random Forest Cat+Numeric ROC
plt.plot(rf_cat_fpr, rf_cat_tpr, label='RF Cat+Num (area = %0.2f)' % rf_cat_auc)


plt.xlim([0.0, 1.0])
plt.ylim([0.0, 1.05])
plt.xlabel('False Positive Rate')
plt.ylabel('True Positive Rate')
plt.title('ROC Graph')
plt.legend(loc="lower right")
plt.show();

Important Parameters


Parameters that will make your model better

  • max_depth: The depth size of a tree
  • n_estimators: The number of trees in the forest. Generally, the more trees the better accuracy, but slower computation.
  • max_features: The max number of features that the algorithm can assign to an individual tree. Try ['auto', 'None', 'sqrt', 'log2', 0.9 and 0.2]
  • min_samples_leaf: The minimum number of samples in newly created leaves. Try [1,2,3]. If 3 is best, try higher numbers.

Parameters that will make your model faster

  • n_jobs: Determines the amount of multiple processors should be used to train/test the model. Always use -1 to use max cores and it'll run much faster
  • random_state: Set this to a number (42) for reproducibility. It's used to replicate your results and for others as well.
  • oob_score Random Forest's custom validation method: out-of-bag prediction

max_depth

The more depth (deeper the tree) means the higher chance of overfitting

In [26]:
results  =  []
results2 = []
max_depth_size  = [1,2,3,4,5,10,20,50,100]
In [49]:
for depth in max_depth_size:
    model = RandomForestClassifier(depth, oob_score=True, n_jobs=-1, random_state=44)
    #model.fit(X, y)
    model.fit(X_train, y_train)
    print(depth, 'depth')
    pred = model.predict(X_train)
    pred2 = model.predict(X_test)
    roc1 = roc_auc_score(y_train, pred)
    roc2 = roc_auc_score(y_test, pred2)
    print('AUC Train: ', roc1)
    print('AUC Test: ', roc2)
    results.append(roc1)
    results2.append(roc2)
    print (" ")
Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
1 depth
AUC Train:  0.8967997848594863
AUC Test:  0.7148005148005149

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=2, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
2 depth
AUC Train:  0.8932029043969343
AUC Test:  0.725868725868726

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=3, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
3 depth
AUC Train:  0.9289363990856528
AUC Test:  0.8021879021879021

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=4, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
4 depth
AUC Train:  0.9364999327685894
AUC Test:  0.7866795366795367

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=5, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
5 depth
AUC Train:  0.9539969073551162
AUC Test:  0.7906692406692406

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=10, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
10 depth
AUC Train:  0.9645186231007127
AUC Test:  0.783912483912484

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=20, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
20 depth
AUC Train:  0.9719813096678769
AUC Test:  0.7954311454311453

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=50, n_jobs=-1,
                       oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
50 depth
AUC Train:  0.9790910313298373
AUC Test:  0.7791505791505791

Out[49]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=100,
                       n_jobs=-1, oob_score=True, random_state=44, verbose=0,
                       warm_start=False)
100 depth
AUC Train:  0.9805701223611671
AUC Test:  0.7656370656370656

In [28]:
plt.plot(max_depth_size, results, label='Train Set')
plt.plot(max_depth_size, results2, label='Test Set')
plt.xlabel('Max Depth Size')
plt.ylabel('AUC Score')
plt.title('Train VS Test Scores')
plt.legend(loc="lower right")
plt.show();

n_estimators

Generally the more trees the better. You'll generalize better with more trees and reduce the variance more. The only downside is computation time.

In [65]:
results  =  []
results2 = []
n_estimator_options = [1, 2, 3, 4, 5, 15, 20, 25, 40, 50, 70, 100]
In [66]:
for trees in n_estimator_options:
    model = RandomForestClassifier(trees, oob_score=True, random_state=42)
    model.fit(X_train, y_train)
    print(trees, 'trees')
    AUC = model.oob_score_
    print('AUC: ', AUC)
    results.append(AUC)
    print (" ")

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
1 trees
AUC:  0.6643258426966292

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=2,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
2 trees
AUC:  0.6867977528089888

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=3,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
3 trees
AUC:  0.7289325842696629

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=4,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
4 trees
AUC:  0.7514044943820225

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=5,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
5 trees
AUC:  0.7556179775280899

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=15,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
15 trees
AUC:  0.7893258426966292

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=20,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
20 trees
AUC:  0.7963483146067416

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=25,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
25 trees
AUC:  0.7935393258426966

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=40,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
40 trees
AUC:  0.797752808988764

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=50,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
50 trees
AUC:  0.7963483146067416

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=70,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
70 trees
AUC:  0.797752808988764

Out[66]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=100,
                       n_jobs=None, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
100 trees
AUC:  0.7991573033707865

In [67]:
pd.Series(results, n_estimator_options).plot();

Max Features

  • It is a good convention to consider the default value of this parameter, which is set to square root of the number of features present in the dataset.
  • The ideal number of max_features generally tend to lie close to this value
In [68]:
results = []
max_features_options = [0.7, 0.2, "auto", "sqrt", "log2"]
In [69]:
for max_features in max_features_options:
    model = RandomForestClassifier(n_estimators=1000, oob_score=True, n_jobs=-1, random_state=42, max_features=max_features)
    model.fit(X_train, y_train)
    print(max_features, "option")
    auc = model.oob_score_
    print('AUC: ', auc)
    results.append(auc)
    print (" ")
Out[69]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features=0.7, max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
0.7 option
AUC:  0.7963483146067416

Out[69]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features=0.2, max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
0.2 option
AUC:  0.7991573033707865

Out[69]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
auto option
AUC:  0.7991573033707865

Out[69]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='sqrt', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
sqrt option
AUC:  0.7991573033707865

Out[69]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='log2', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
log2 option
AUC:  0.7991573033707865

In [70]:
pd.Series(results, max_features_options).plot();

Min Sample Leafs

  • We can control the growth of a tree by setting a minimum sample leafs criterion for terminal/leaf nodes.
  • This hyperparameter also helps prevent overfitting as the parameter value increases
In [35]:
results = []
min_samples_leaf_options = [1, 2, 3, 4, 5, 6, 7, 8, 9, 10,20]
In [36]:
for min_samples in min_samples_leaf_options:
    model = RandomForestClassifier(n_estimators=1000, oob_score=True, n_jobs=-1, random_state=42, max_features="auto", min_samples_leaf=min_samples)
    model.fit(X_train, y_train)
    print(min_samples, "min samples")
    auc = model.oob_score_
    print('AUC: ', auc)
    results.append(auc)
    print (" ")

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=1, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
1 min samples
AUC:  0.7991573033707865

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=2, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
2 min samples
AUC:  0.8216292134831461

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=3, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
3 min samples
AUC:  0.8188202247191011

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=4, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
4 min samples
AUC:  0.8286516853932584

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=5, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
5 min samples
AUC:  0.8258426966292135

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=6, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
6 min samples
AUC:  0.8174157303370787

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=7, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
7 min samples
AUC:  0.8132022471910112

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=8, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
8 min samples
AUC:  0.8117977528089888

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=9, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
9 min samples
AUC:  0.8103932584269663

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=10, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
10 min samples
AUC:  0.8075842696629213

Out[36]:
RandomForestClassifier(bootstrap=True, class_weight=None, criterion='gini',
                       max_depth=None, max_features='auto', max_leaf_nodes=None,
                       min_impurity_decrease=0.0, min_impurity_split=None,
                       min_samples_leaf=20, min_samples_split=2,
                       min_weight_fraction_leaf=0.0, n_estimators=1000,
                       n_jobs=-1, oob_score=True, random_state=42, verbose=0,
                       warm_start=False)
20 min samples
AUC:  0.8047752808988764

In [37]:
pd.Series(results, min_samples_leaf_options).plot();

Best Practice for Interpreting Random Forest

Interpreting Individual trees

In [38]:
# The amount of trees used to ensemble
model_2.estimators_
Out[38]:
[DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=1751002438, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=618510555, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=237795335, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=481769637, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=1239247864, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=880598456, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=1233966386, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=622968513, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=1934241036, splitter='best'),
 DecisionTreeClassifier(class_weight=None, criterion='gini', max_depth=None,
                        max_features='auto', max_leaf_nodes=None,
                        min_impurity_decrease=0.0, min_impurity_split=None,
                        min_samples_leaf=1, min_samples_split=2,
                        min_weight_fraction_leaf=0.0, presort=False,
                        random_state=370284359, splitter='best')]
In [99]:
Xx = pd.read_csv('titanic_train.csv')
round(Xx.Survived.value_counts(1), 2)
Out[99]:
0    0.62
1    0.38
Name: Survived, dtype: float64

Visualize a single decision tree

Each node in a tree contains:

  1. The splitting criteria of the attribute (Sex_male <= 0.5)
  2. Has the bootstrap sample (ex. 451/712 --> 67% of the data)
  3. Class value of the sample (ex. [448, 264] --> 448 0's, 264 1's)
  4. Final class outcome (classification is majority vote, regression is MSE)
  5. Cost Function (Gini - used to interpret how good of a split we made)

Gini

  • We use the Gini Index as our cost function used to evaluate splits in the dataset.
  • A Gini score gives an idea of how good a split is by how mixed the classes are in the two groups created by the split.
  • A perfect separation results in a Gini score of 0 (ex. [0,25])
  • Whereas the worst case split that results in 50/50 classes.
In [ ]:
# Load libraries
import pydotplus

from sklearn import tree
from sklearn import datasets
from IPython.display import Image
from sklearn.tree import DecisionTreeClassifier
In [ ]:
m = RandomForestClassifier(n_estimators=1, max_depth=3)
m = m.fit(X_train, y_train)

# Create DOT data
dot_data = tree.export_graphviz(m.estimators_[0], out_file=None,
                                feature_names=X_train.columns,
                                class_names=True)

# Draw graph
graph = pydotplus.graph_from_dot_data(dot_data)
In [41]:
# Show graph
Image(graph.create_png())
Out[41]:

Visualize Entire Decision Tree

In [ ]:
# Load libraries
import pydotplus

from IPython.display import Image
from sklearn.tree import export_graphviz
from sklearn.externals.six import StringIO
In [ ]:
# Create DOT data
dot_data = StringIO()
export_graphviz(model_2.estimators_[0], out_file=dot_data,
                filled=True, rounded=True,
                special_characters=True)
graph = pydotplus.graph_from_dot_data(dot_data.getvalue())
In [42]:
# Show graph
Image(graph.create_png())
Out[42]:

Interpreting Feature Importance

Feature selection - implicit feature selection whereas models like LASSO is explicit.

A feature’s importance is the increase in the model’s prediction error after we permuted the feature’s values (breaks the relationship between the feature and the outcome).

What does it mean: The important features are more correlated with the dependent variable and contribute more variance to the dependent varaible.

How does it work:

  1. Train Random Forest Model
  2. Find prediction score of model (benchmark score)
  3. For each feature, shuffle it's value to alter it and look at prediction performance.
  4. Compare it with benchmark score. If the altered feature hurts the score, then it's a bad feature.

Note: Feature importance only gives you notion which features contributes to the decision, not "which way", because sometimes it will work one way, and sometimes the other way.

If you work with linear models then there is quite simple distinction if feature is "positive" or "negative", because the only impact it can have on the final result is being added (with weight).

However, ensemble of decision trees can have arbitrary complex rules for each feature, for example "if book has red cover and have more than 100 pages then if it contains dragons it gets high score" but "if book has blue cover and more than 100 pages then if it contains dragons it gets low score" and so on.

In [43]:
model_2.feature_importances_
Out[43]:
array([6.80748759e-02, 2.24240737e-01, 6.92844117e-02, 3.76706126e-02,
       2.06602815e-01, 1.52019649e-01, 1.24476553e-01, 2.13730604e-03,
       5.80274670e-03, 1.43312769e-02, 1.11597845e-02, 1.61675035e-02,
       3.77872119e-03, 3.10565152e-03, 2.61347026e-02, 1.52152843e-04,
       1.50912809e-02, 0.00000000e+00, 5.61791538e-03, 1.41513042e-02])
In [44]:
feature_importances = pd.Series(model_2.feature_importances_, index=X.columns)
print(feature_importances)
feature_importances.sort_values(inplace=True)
feature_importances.plot(kind='barh', figsize=(7,6))
Pclass              0.068075
Age                 0.224241
SibSp               0.069284
Parch               0.037671
Fare                0.206603
Sex_female          0.152020
Sex_male            0.124477
Cabin_A             0.002137
Cabin_B             0.005803
Cabin_C             0.014331
Cabin_D             0.011160
Cabin_E             0.016168
Cabin_F             0.003779
Cabin_G             0.003106
Cabin_None          0.026135
Cabin_T             0.000152
Embarked_C          0.015091
Embarked_Missing    0.000000
Embarked_Q          0.005618
Embarked_S          0.014151
dtype: float64
Out[44]:
<matplotlib.axes._subplots.AxesSubplot at 0x1ff349c9278>

Combine the categorical features into one feature importance

In [45]:
model_2.feature_importances_.max()
Out[45]:
0.2242407369320265
In [46]:
# Create function to combine feature importances
def graph_feature_importances(model, feature_names, autoscale=True, headroom=0.1, width=10, summarized_columns=None):
    feature_dict=dict(zip(feature_names, model.feature_importances_))

    if summarized_columns:
        for col_name in summarized_columns:
            sum_value = sum(x for i, x in feature_dict.items() if col_name in i )
            keys_to_remove = [i for i in feature_dict.keys() if col_name in i ]
            for i in keys_to_remove:
                feature_dict.pop(i)
            feature_dict[col_name] = sum_value
    results = pd.Series(feature_dict, index=feature_dict.keys())
    results.sort_values(inplace=True)
    print(results)
    results.plot(kind='barh', figsize=(width, len(results)/4), xlim=(0, .30))

In [47]:
# Create combined feature importances
graph_feature_importances(model_2, X.columns, summarized_columns=categorical_variables)
Embarked    0.034861
Parch       0.037671
Pclass      0.068075
SibSp       0.069284
Cabin       0.082770
Fare        0.206603
Age         0.224241
Sex         0.276496
dtype: float64

Conclusion

In Summary

Random Forest :

  • works for both regression and classification problems
  • needs minimal data cleaning
  • can provide feature importance
  • has built in cross validation
  • needs little hyper-parameter tuning
  • treats different scaling of features similarly
  • natively detects non linear interactions
